Yuli photoelectric double-sided grinding machine and grinding disc

Dec 26, 2023

Product advantages:

1, the frequency converter with frequency conversion motor drive, to achieve soft start, soft stop, speed stability, small impact;

2, the use of double motor drive, the upper and lower grinding disc and the inner gear ring by a main motor drive, frequency control. The sun wheel is driven by a secondary motor frequency conversion speed regulation, the speed change range is wider, the working speed ratio can be controlled immediately and accurately, and can adapt to the requirements of different grinding processes;

3. The sun wheel and the inner gear ring are lifted synchronously to meet the requirements of taking and releasing workpieces and adjusting the meshing position of the cruise ship;

4. The upper and lower grinding disc is driven by helical gear, which improves the smoothness of operation;

5, PLC control, pressure using electric - gas proportional valve closed-loop feedback control, pressure level setting more convenient and accurate, easy to operate, reliable and stable work;

6, the machine application man-machine interface (PT) display and PLC control, on the one hand display the operating parameters, on the other hand through its touch adjustment set the process parameters, the main operation is completed by the ordinary button;

7, the shape and internal structure fully consider the convenience of operation and maintenance.

Technical parameters:

1. Grinding disc specification: φ1136×φ354×50mm

2. Maximum grinding diameter: φ350mm

3. Cruise ship parameters: British DP12 Z-200

4. Minimum grinding thickness: 0.3mm

5. Maximum grinding thickness: 30mm

6. Main motor: 11kw

7, sun wheel drive motor: 1.5kw

8. Lower grinding disc speed: 0-50rpm

9, lifting motor: 0.75kw

Sand pump motor: 0.37kw
